| Brightness | ||
| Brightness (Marketing) ( Ansi Lumens ) | 7500 | |
| Overall Spec | ||
| Panel | Display Panel | 0.65″ DMD Chip |
| Display Technology | DLP | |
| Native Resolution | WXGA (1280×800) | |
| Lamp | Lamp Consumption(W) | 350＊2 |
| Lamp Lifetime(H) | Double－Normal:2000hrs/ECO:4000hrs Single-Normal:4000hrs/ECO:8000hrs | |
| Projection Lens | Zoom/Focus | Powered 1.35:1 |
| Throw Ratio | 100″@3.8m | |
| F | 2.0-2.4 | |
| f | 24.5-33.1mm | |
| Zoom Ratio | 1.35x optics | |
| Screen size | 40″~300″ | |
| Lens Shift V | ±55% | |
| Lens Shift H | ±10% | |
| CR | Contrast Ratio | 15000:1 |
| Noise | Noise (dB)@1m | 36dB |
| Uniformity | Uniformity(Actual Min) -JISX6911 | 80% |
| AR | Aspect Ratio | 16:10 (Standard)/4:3(Compatible) |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| BNC | *5 | |
| DVI-D (with HDCP) | *1 | |
| Video | *1 | |
| S-Video | *1 | |
| HDMI | *1 | |
| Audio in (L/R)–RCA | N/A | |
| USB-Type A | N/A | |
| USB-Type B | N/A | |
| RJ45 | N/A | |
| Output | VGA | *1 |
| Audio out (mini-jack,3.5mm) | N/A | |
| Other Interface | N/A | |
| Control | RS232 Input | *1 |
| RS233 Output | *1 | |
| RJ45 | *1 | |
| Remote 1(RS232) | *1 | |
| Wired remote(IN) | *1 | |
| Wired remote(OUT) | *1 | |
| Other Interface | N/A | |
| General Spec | ||
| Audio | Speaker | N/A |
| Power Consumption | Power Requeirements | 100~240V@ 50/60Hz |
| Power Consumption | 830W | |
| Standby Mode (ECO) Power Consumption | <0.5W | |
| Temp.&Humidity | Operating Temp. | 0℃~40℃(35~ ECO) |
| Store Temp. | -20℃~~60℃ | |
| Oparating Humidity | 20%~85% | |
| Storage Humidity | 10%~85% | |
| Mechanical Design | Security bar | Yes |
| Password protections | Yes | |
| Control Panel Lock | Yes | |
| Kenginston Lock | Yes | |
| Ventilation (In/Ex) | Side/Side | |
| Lamp access | Side | |
| Filter access | Side | |
| ESD-dust filter | Yes(HEPA) | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30° H：±15° Pincushion/Barrel Correction Corner Keystone |
| OSD | Languages | 19 languages： Simplfied Chinese,English,French, Spanish,Portuguese,German,Italian,Japanese,Korean,Russian,Finnish,Dutch,Thai, Vietnamese,Turkey,Afrikaans,Indonesian,Farsi,Arabic |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 48~85Hz | |
| Display Resolution | Computer Signal Input | 640×400~1920×1200 |
| Video Signal Input | PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i,SCART | |
| SW setting | Auto Setup | INPUT SEARCH,AUTO PC, |
| Audio muting(Muting) | Yes | |
| Suspend | Yes(5miniutes no singnal as default) | |
| Picture mode | Dynamic、Standard、Cinema、 Blackboard、Colorboard | |
| Lamp mode | NORMAL,ECO | |
| Filter Cleaning Cycle | 100/200/300 hours | |
| Cooling time | 60s,90s | |
| Closed caption | Yes | |
| High altitude | Yes(1400~2700m) | |
| Signal Power On | Yes | |
| Turn on countdown | 10s | |
| Auto Ceiling | N/A | |
| D-Zoom | 1~16 | |
| Others | Edge Blending | |
| Dimension&Weight | ||
| MAX Dimensions (WxHxD mm) | 490X201X421mm( Without Bulge) | |
| Net. Weight (KG) | 16kg | |
| Bundled Items | ||
| Manual Languages | Chinese, English | |
| Standard Accessaries | Power cord, VGA cable, Remote control&Battery, | |
